• Type of LampLED
• Voltage (V DC)10-48V DC
• Theoretical effect (w) 12V72
• Theoretical effect (w) 24V70
• Consumption (w) 12V75
• FunctionsWhite position lights,Amber position lights,Driving lights
• Theoretical lumen6200
• Actual lumen5010
• 1 LUX @ m363
• Kelvin6000
• IP-class68
• Color housingBlack
• Color lensClear
• Color LED´sAmber & White
• Beam patternCombo
• Position lightYes
• ConnectionDT4
• Cable length (mm)500
• Material bracketside bracket: 304 stainless steel, sliding bracket: Aluminium
• Material housing/chassiAluminium
• Material lensPC
• Length (mm)277
• Depth (mm)70
• Height (mm)38,5
• Height including bracket (mm)56
• CC (mm)249
• Operating temperature-40 - +65°C
• ADR-approvedNo
• E-approvedYes
• According to regulationECE R148, R149
• Reference number25

EMCECE R10
